Fishing Chain

Brand Name : Zhongyuan

Model Number : Standard and Customized

Certification : CCS, NK, BV, ABS, DNV-GL, LR, KR, IRS, RS, RINA, Makers Test Certificate, Etc.

Place of Origin : China

MOQ : 1

Price : As per quotation

Payment Terms : TT, L/C, Etc.

Supply Ability : Satisfy clients needs

Delivery Time : As per offer

Packaging Details : Pallet or Customized

Type : Fishing Chain

Material : Carbon Steel or Stainless Steel

Surface Treatment : Electroplating etc

Structure : Flash Butt Welded Chain

Feature : Heat Resistant

Color : Solid Color

Standard : ISO9001, CE, BV

Contact Now

Fishing Chain



Description:

Fishing chain belongs to the type of welding chain, which can be used as transmission chain, drag chain, conveying chain and special chain. It is generally transported through plywood box / wooden bag / hemp bag / steel barrel + pallet. It has passed the certification of ISO9001, CE and BV. It is heat-resistant and high-temperature resistant, and is widely used in life.


Main Technical Specifications:

  1. Type:Fishing Chain
  2. Material:Carbon Steel or Stainless Steel
  3. Surface Treatment:Electroplating etc
  4. Structure:Flash Butt Welded Chain
  5. Feature:Heat Resistant
  6. Color:Solid Color
  7. Standard:ISO9001, CE, BV


Main Technical Parameters:

ype Nominal Diameter Pitch(mm) Width (mm) Weight

Breaking Load

Min.

KN
Inside Min. Outside Max. kg/m
Short Link Chain 7 21 10 25.5 1.05 6o
10 30 14 36 2.2 125
13 39 18.1 47.1 3.8 214
16 48 22.4 57.4 5.63 320
19 57 27.8 68.8 7.81 450
20 60 29 72 8.52 600
Mid Link Chain 10 40 15 37 1.9 125
13 52 19.5 48.5 3.31 214
14 50 18.5 49.5 4 250
16 64 24 59 4.97 320
19 76 28.5 69.5 6.92 450
22 86 27 74 9.5 610
26 92 32 86 13.7 850
Long Link Chain 7 45 10 25.5 0.82 60
9 53 15 35 1.36 100
11 63 18 43 2.16 152
13 80 22 51 2.93 214
16 100 26 61 4.34 320
19 100 27 68 6.31 450
22 120 37 84 8.74 610
28 150 44 103 14.41 980
